VACUUM COMPATIBLE & HIGH RESOLUTION | DESIGNED FOR VACUUM DOWN TO 10-6 mbar
- Vacuum compatibility > 10-6 mbar
- High resolution 160 x 120 phase pixels
- Spectral range from 400 nm to 1100 nm
- Diverging beam compatible
- Invariant to thermal and mechanical vacuum constraints
- Tolerates vacuum-cycles without any performance decrease
- Both functional under vacuum and atmospheric pressure
- Low outgassing
Specifications
| Vacuum compatibility | > 10-6 mbar |
| Wavelength range | 400 - 1100 nm |
| Aperture dimension | 4.73 x 3.55 mm2 |
| maximum NA (optional software necessary) | 0.2 |
| Spatial resolution | 29.6 µm |
| Phase & intensity sampling | 160 x 120 |
| Accuracy | 15 nm RMS |
| Resolution (Phase) | 2 nm RMS |
| Acquisition rate | 60 fps |
| Real-time processing frequency | 7 Hz (full resolution) |
| Interface | Giga Ethernet |
| MTBF | > 10 years |
| Dimensions (w x h x l) | 54 x 46 x 75.3 mm |
| Weight | ~ 250 g |
